Expand your operational capacity with this 2019 Sany SY205C excavator, currently located in Hangzhou, Zhejiang. Built for contractors managing multiple jobsites simultaneously, this 20-ton machine delivers reliable performance as a fleet addition or standby unit. Powered by a 118kW engine at 2000 rpm, it handles demanding earthmoving tasks with 138kN bucket digging force and 109kN arm digging force. The 0.9-1.1m³ bucket capacity matches industry-standard productivity requirements for medium-duty applications.
- Working Weight: 21,500 kg with proven stability
- Reach Specs: 10,280mm max digging radius, 6,600mm max depth
- Mobility: 2,900mm rear turning radius for confined spaces
- Transport Dimensions: 9,680mm (L) × 2,980mm (W) × 3,440mm (H)
- Gradeability: 70% (35°) climbing capability on challenging terrain
Manufactured in China with traditional hydraulic power systems, this SY205C integrates seamlessly into existing Sany fleets or serves as a cost-effective backup for peak demand periods. Ready for immediate deployment across construction, excavation, and utility projects requiring proven 20-t
| Specifications | Value |
|---|---|
| No. | 1027499 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
