Product Description
Discover the 2019 Sany SY205C, a robust and reliable excavator designed for demanding earthmoving tasks. Located in Jiangxi, China, this used machine is equipped with new chains, ensuring enhanced durability and performance on your job site. Ideal for construction, mining, and infrastructure projects, the SY205C offers a blend of power, efficiency, and ease of maintenance. This model is known for its sturdy build and operational flexibility, making it a valuable addition to any fleet. Contact us for more details or to discuss purchasing options.
- Year: 2019
- Brand: Sany
- Model: SY205C
- Location: Jiangxi, China
- New Chains Installed
| Specifications | Value |
|---|---|
| No. | 1133801 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
