Product Description
Acquiring proven performance doesn't require a new-equipment budget. This 2020 Sany SY205C excavator from Jinan, Shandong delivers full-scale productivity at a fraction of factory pricing—a strategic choice for contractors maximizing ROI without compromising capability.
Powered by a robust 118 kW engine, this 20-ton workhorse generates 138 kN bucket digging force and reaches 10,280 mm maximum digging radius. With 0.9–1.1 m³ bucket capacity and dual travel speeds (5.4/3.3 km/h), it handles demanding earthmoving, trenching, and loading operations across diverse job sites. The 70% climbing ability and 440 mm ground clearance ensure reliable mobility on challenging terrain.
Compact transport dimensions (9,680 × 2,980 × 3,440 mm) simplify logistics while maintaining professional-grade specs. Minimal operational hours on this China-manufactured unit mean extended service life ahead—delivering the reliability of late-model equipment without the depreciation hit of new machinery.
- Working Weight: 21,500 kg
- Max Digging Depth: 6,600 mm
- Rated Power: 118 kW @ 2,000 rpm
- Location: Jinan, Shandong, China
| Specifications | Value |
|---|---|
| No. | 1018955 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
