Product Description
Powered by a robust 118 kW engine operating at 2000 rpm, this 2020 Sany SY205C excavator delivers exceptional hydraulic performance engineered for demanding applications. Operating at 20 tons with a working weight of 21,500 kg, this Chinese-manufactured machine combines proven mechanical design with reliable traditional power systems. The hydraulic system generates impressive digging forces—138 kN bucket force and 109 kN arm force—enabling efficient material handling across diverse job sites.
Technical specifications demonstrate superior engineering quality:
- Maximum digging reach of 10,280 mm with 6,600 mm depth capability
- 0.9-1.1 m³ backhoe bucket capacity for optimal productivity
- 47.3 kPa ground pressure minimizes surface disturbance
- 70% (35°) grading ability tackles challenging terrain
- Dual travel speeds (5.4/3.3 km/h) for operational flexibility
- Compact 2,900 mm rear turning radius enhances maneuverability
Currently located in Hangzhou, Zhejiang, this SY205C represents Sany's commitment to durable construction machinery. The 11 rpm swing speed and 3,730 mm front turning radius ensure precise positioning in confined spaces, while the 600 mm track pla
| Specifications | Value |
|---|---|
| No. | 1024203 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
