Product Description
Expand your operational capacity with this 2020 Sany SY205C excavator, a proven 20-ton workhorse engineered for fleet reliability. Powered by a robust 118kW engine delivering 138kN bucket digging force and 109kN arm force, this machine handles demanding excavation, trenching, and loading tasks without hesitation. Its 10,280mm maximum reach and 6,600mm digging depth provide the versatility busy contractors need when primary equipment is deployed elsewhere.
Currently located in Hunan, China, this unit offers:
- 21,500kg working weight with 0.9-1.1m³ bucket capacity for productive cycle times
- Compact 2,900mm rear turning radius enabling work in confined job sites
- 5.4km/h travel speed for efficient repositioning between tasks
- 70% grading ability and 440mm ground clearance for challenging terrain
- 9,680mm transport length fitting standard lowboy trailers
Built by Sany's manufacturing facilities in China, the SY205C serves as the ideal backup unit or fleet expansion tool. When your lead machines are committed to long-term projects, this excavator keeps secondary contracts moving forward. Available for immediate inspection and global shipping through Fair Trade Machinery.
| Specifications | Value |
|---|---|
| No. | 1024659 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
