2020 Sany SY205C

Engineered with a robust 118 kW power plant delivering peak torque at 2,000 rpm, this 2020 Sany SY205C excavator combines proven hydraulic architecture with precision control systems. The 20-ton platform generates 138 kN bucket digging force and 109 kN arm digging force, enabling operators to tackle demanding excavation tasks across diverse soil conditions. Operating weight of 21,500 kg provides exceptional stability during heavy lifting and high-reach operations.

• Maximum digging reach: 10,280 mm with 6,600 mm depth capability
• Bucket capacity: 0.9–1.1 m³ optimized for material handling efficiency
• Advanced undercarriage: 600 mm track shoes, 3,360 mm ground contact length
• Superior mobility: 70% gradeability (35°) with dual travel speeds
• Compact transport dimensions: 9,680 × 2,980 × 3,440 mm
• Low ground pressure: 47.3 kPa minimizes surface disturbance

Currently located in Shaoxing, Zhejiang, this China-manufactured machine represents Sany's commitment to hydraulic performance and structural durability in the mid-size excavator segment.
