Product Description
Built for precision and all-day productivity, this 2020 Sany SY205C delivers 20-ton performance with operator-centric engineering. Powered by a robust 118kW engine at 2000 rpm, this excavator combines 138kN bucket digging force with exceptional stability across demanding jobsites. The spacious cab sits at 3075mm height, offering commanding 360-degree visibility for safer operation around obstacles and personnel.
- Operator Comfort: Full-height cabin design minimizes fatigue during extended shifts, with intuitive controls for responsive handling
- Stable Platform: 21,500kg working weight and 2380mm track gauge ensure solid footing on slopes up to 35° (70% grade)
- Versatile Reach: 10,280mm maximum digging radius and 6,600mm depth tackle utility work, foundation prep, and material handling
- Efficient Mobility: Dual travel speeds (5.4/3.3 km/h) and 2900mm rear swing radius enable tight maneuvering in confined areas
- Ready to Work: Standard 0.9-1.1m³ backhoe bucket, currently located in Liuzhou, Guangxi
| Specifications | Value |
|---|---|
| No. | 1041717 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
