Product Description
Built in 2020, this Sany SY205C medium-duty excavator delivers proven performance with the long-term support that keeps machines profitable. Operating at 20 tons with a robust 118kW engine, this backhoe-equipped unit handles demanding excavation work with 138kN bucket digging force and a maximum reach of 10,280mm. Sany's established global parts network ensures minimal downtime—critical when evaluating used equipment investments.
- Working Weight: 21,500kg with 0.9-1.1m³ bucket capacity
- Performance Specs: 6,600mm max digging depth, 9,600mm max digging height
- Operational Efficiency: 5.4km/h travel speed, 70% climbing ability
- Transport Dimensions: 9,680mm length × 2,980mm width × 3,440mm height
- Location: Wenzhou, Zhejiang Province, China
Sany's reputation for parts availability and strong resale value makes this SY205C a strategic purchase. With factory-backed component sourcing and widespread dealer infrastructure, maintenance costs remain predictable. Currently located in Wenzhou, this machine represents reliable Chinese engineering with global support—a combination that protects your in
| Specifications | Value |
|---|---|
| No. | 1045295 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
