Product Description
Discover the 2020 Sany SY205C, a robust and reliable excavator available in Jiangxi, China. This machine, with over 100,000 operational hours, is designed to meet the demanding needs of construction and excavation projects. Built for durability and efficiency, the SY205C features Sany's trusted engineering, ensuring optimal performance on any job site. Ideal for contractors and industrial operations, this excavator combines power, precision, and productivity, making it a valuable addition to your fleet.
- Year: 2020
- Brand: Sany
- Model: SY205C
- Location: Jiangxi, China
- Operational Hours: Over 100,000
| Specifications | Value |
|---|---|
| No. | 1102427 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
