Product Description
Built for immediate deployment, this 2021 Sany SY205C crawler excavator delivers 20-ton performance across demanding job sites. Powered by a robust 118kW engine at 2000 rpm, this machine handles deep foundation work, trenching, and material loading with professional-grade efficiency. The 0.9-1.1m³ bucket configuration provides optimal balance between cycle times and payload capacity for earthmoving contractors.
Operational specifications prove site-ready capability:
- Maximum digging depth reaches 6600mm for utility installation and basement excavation
- 10280mm working radius covers extensive work zones without repositioning
- 138kN bucket digging force breaks through compacted soil and rocky substrates
- Compact 2980mm transport width enables road-legal mobilization between projects
- 70% gradeability (35°) maintains traction on sloped terrain and loading ramps
Currently located in Dongguan, Guangdong, this Chinese-manufactured excavator combines proven hydraulic architecture with straightforward maintenance access. Dual travel speeds (5.4/3.3 km/h) optimize productivity during digging cycles and site repositioning. Ready for grading, demolition prep, and high-volume ex
| Specifications | Value |
|---|---|
| No. | 1027103 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
