Product Description
Engineered with a robust 118kW power plant delivering peak torque at 2000 rpm, this 2021 Sany SY205C combines hydraulic precision with field-proven durability. Operating at 21,500 kg working weight, the excavator generates 138 kN bucket digging force and 109 kN arm digging force—critical metrics for demanding excavation work across mining, demolition, and infrastructure projects.
Built on Sany's advanced SY-C platform, this 20-ton machine features optimized hydraulic flow management that maximizes productivity while minimizing fuel consumption. The excavator's 0.9-1.1 m³ bucket capacity handles material efficiently, supported by a 10,280 mm maximum digging radius and 6,600 mm depth capability. With 70% grading ability and 440 mm ground clearance, the unit maintains stability on challenging terrain.
Core Technical Specifications:
- Rated Power: 118 kW @ 2000 rpm
- Bucket Force: 138 kN | Arm Force: 109 kN
- Working Weight: 21,500 kg
- Maximum Reach: 10,280 mm | Dig Depth: 6,600 mm
- Ground Pressure: 47.3 kPa (600 mm track shoes)
- Location: Nanchang, Jiangxi—ready for inspection
| Specifications | Value |
|---|---|
| No. | 1027621 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
