Product Description
Built for demanding jobsites, this 2021 Sany SY205C delivers immediate productivity across excavation, grading, and material handling operations. With a 20-ton working weight and 118kW rated power at 2000 rpm, this backhoe excavator tackles deep trenching with a maximum digging depth of 6,600mm and handles heavy loads with 138kN bucket digging force. The 0.9-1.1m³ bucket capacity moves substantial material volumes per cycle, while the 10,280mm maximum digging radius provides extensive reach for foundation work and site preparation.
Operational efficiency comes standard. Ground-specific pressure of 47.3 kPa minimizes surface disruption on sensitive terrain. The machine climbs 70% grades and rotates at 11 rpm for quick repositioning between cuts. Transport dimensions of 9,680mm length and 2,980mm width allow straightforward site-to-site mobilization. Currently located in Shenzhen, Guangdong, this Chinese-manufactured excavator is inspection-ready and prepared for immediate deployment on your next project.
- Maximum unloading height: 6,730mm
- Travel speed: 5.4/3.3 km/h
- Minimum turning radius: 3,730mm (front device)
- Track gauge: 2,380mm with 600mm plates
| Specifications | Value |
|---|---|
| No. | 1034179 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
