Product Description
Ready to deploy in Guangzhou, this 2021 Sany SY205C excavator eliminates factory wait times and accelerates your project timeline. Equipped with a robust 118 kW engine and 20-ton operating capacity, this machine delivers reliable performance across demanding earthmoving applications. Skip the months-long procurement cycle—this unit is available for immediate inspection and fast delivery to your site.
- Operating Weight: 21,500 kg with optimal stability
- Bucket Capacity: 0.9-1.1 m³ for efficient material handling
- Maximum Digging Reach: 10,280 mm extends your work envelope
- Maximum Digging Depth: 6,600 mm tackles deep excavation tasks
- Digging Forces: 138 kN bucket / 109 kN stick for tough ground conditions
- Travel Speed: 5.4/3.3 km/h for efficient site mobility
- Climbing Ability: 70% (35°) handles challenging terrain
Positioned in Guangzhou, Guangdong Province, this excavator offers streamlined logistics throughout Southeast Asia and domestic markets. Avoid production delays and secure a proven 2021 model that's inspection-ready
| Specifications | Value |
|---|---|
| No. | 1043339 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
