Product Description
Built for high-output excavation work, this 2021 Sany SY205C delivers 20-ton performance across digging, grading, and demolition applications. Powered by a robust 118kW engine at 2000rpm, this crawler excavator generates 138kN bucket digging force and 109kN arm digging force—sufficient power to tackle compacted soil, rock breaking, and foundation work without hesitation.
Currently located in Wenzhou, Zhejiang, this machine arrives site-ready with proven capabilities:
- Maximum digging depth of 6600mm and reach extending to 10280mm for deep trenching and slope work
- 0.9–1.1m³ backhoe bucket capacity optimized for loading trucks and mass excavation
- Operating weight of 21,500kg provides stability during heavy lifting and demolition tasks
- 70% gradeability (35°) enables operation on challenging terrain and embankments
- 600mm track plates with 47.3kPa ground pressure minimize surface damage on sensitive sites
Factory-built in China with traditional hydraulic power systems, this SY205C requires no adaptation period. Operators can immediately deploy this excavator for utility installation, site preparation, or material handling operations.
| Specifications | Value |
|---|---|
| No. | 1048521 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
