Product Description
Built for high-volume excavation and precision grading, this 2022 Sany SY205C delivers 20-ton performance across construction, demolition, and earthmoving applications. Powered by a robust 118kW engine at 2000 rpm, this mid-size excavator combines 138kN bucket digging force with 109kN arm force to handle dense soil, rock breaking, and foundation work without hesitation. Currently located in Maoming, Guangdong, the machine arrives site-ready with proven Chinese manufacturing quality.
- Maximum digging depth of 6,600mm reaches utility trenches and deep foundation levels efficiently
- 10,280mm working radius covers expansive work zones from a single position
- 0.9-1.1m³ backhoe bucket capacity moves material at production rates
- 5.4/3.3 km/h dual-speed travel system transitions quickly between job zones
- 70% gradeability (35°) tackles sloped terrain and loading ramps confidently
- 21,500kg operating weight provides stability during heavy lifting and demolition cycles
Compact 2,980mm transport width enables road-legal hauling and access to restricted urban sites. Immediate deployment for contractors requiring dependable digging power and operational versatility.
| Specifications | Value |
|---|---|
| No. | 1026683 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
