Product Description
Built for immediate deployment on demanding worksites, this 2022 Sany SY205C medium excavator delivers 118 kW of proven power for digging, grading, and demolition tasks. Operating at 21,500 kg working weight with a 0.9–1.1 m³ bucket capacity, this machine handles foundation work, trenching, and material handling with consistent reliability. Maximum digging depth reaches 6,600 mm while the 10,280 mm working radius covers extensive ground without repositioning.
Powerful hydraulics generate 138 kN bucket digging force and 109 kN arm force, breaking through compacted soil and fractured rock efficiently. The 70% grading ability and 440 mm ground clearance ensure stable operation on uneven terrain. Compact transport dimensions (9,680 mm length, 2,980 mm width) simplify logistics between job sites.
Key Specifications:
- Rated Power: 118 kW @ 2,000 rpm
- Maximum Digging Height: 9,600 mm
- Maximum Dump Height: 6,730 mm
- Travel Speed: 5.4 / 3.3 km/h
- Track Width: 600 mm
- Location: Lishui, Zhejiang, China
Currently positioned in Zhejiang Province, this machine is inspection-ready and available for immediate acquisition.
| Specifications | Value |
|---|---|
| No. | 1027863 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
