Product Description
Built for productivity, this 2022 Sany SY205C excavator delivers 20-ton performance across demanding jobsites. Powered by a robust 118kW engine at 2000rpm, it tackles digging, grading, and demolition tasks with proven reliability. Currently located in Wuxi, Jiangsu, this machine arrives site-ready with minimal downtime between acquisition and deployment.
Key operational specifications include:
- Maximum digging depth of 6,600mm and reach extending to 10,280mm for versatile trenching and foundation work
- Bucket capacity of 0.9-1.1m³ with 138kN digging force, moving material efficiently on every cycle
- 21,500kg working weight provides stability during heavy lifting and material handling operations
- Travel speed up to 5.4km/h with 70% gradeability for rapid repositioning across uneven terrain
- Compact transport dimensions (9,680mm length) simplify logistics and site mobilization
Equipped with traditional power systems and manufactured in China, this excavator combines proven engineering with accessible maintenance. Ready to generate revenue from day one on your construction, excavation, or demolition projects.
| Specifications | Value |
|---|---|
| No. | 1030687 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
