Product Description
Available now from our Hubei facility, this 2022 Sany SY205C excavator eliminates factory lead times and accelerates project deployment. Built for immediate mobilization, this 20-ton workhorse delivers 118kW of rated power and a 1.0m³ bucket capacity—ready to start generating ROI on your site without delay. Skip months of waiting: secure proven Chinese manufacturing quality with instant availability.
- Operating Weight: 21,500 kg with 47.3 kPa ground pressure for versatile terrain handling
- Digging Performance: 10,280mm maximum reach, 6,600mm depth, 138kN bucket force
- Productivity Specs: 11 rpm rotation speed, 5.4 km/h travel speed for efficient cycle times
- Transport Dimensions: 9,680mm length × 2,980mm width × 3,440mm height
- Working Range: 9,600mm max excavation height, 6,730mm max unloading height
- Mobility: 70% (35°) climbing ability, 2,900mm rear turning radius, 440mm ground clearance
Positioned in Hubei for rapid dispatch across domestic and international markets. Bypass procurement delays—this inspection-ready SY205C ships immediately to your construction, mining, or infrastructure project. Contact Fair Trade Machinery today for fast-track delivery coordinat
| Specifications | Value |
|---|---|
| No. | 1037642 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
