Product Description
With a 20-ton capacity and a robust working weight of 21,500 kg, the Sany SY205C excavator is an ideal fleet addition for busy contractors. Featuring a bucket capacity of 0.9 to 1.1 m³, this machine ensures efficient digging and loading operations. Made in China, it boasts a rated power of 118 kW at 2000 rpm, providing reliable performance on any job site.
- Ground specific pressure: 47.3 Kpa
- Travel speed: 5.4/3.3 km/h
- Maximum digging depth: 6600 mm
- Bucket digging force: 138 kN
- Total transport length: 9680 mm
Integrate the SY205C into your fleet for enhanced productivity and reliability. Its 70% climbing ability and 35° gradient capability make it versatile for various terrains. The full cab height of 3075 mm and minimum ground clearance of 440 mm ensure operator comfort and machine durability. Ideal for both primary and backup roles, the SY205C is ready to support your most demanding projects.
| Specifications | Value |
|---|---|
| No. | 1027980 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
