Product Description
With a 20-ton capacity and a working weight of 21,500 kg, the Sany SY205C is an ideal addition to any busy contractor's fleet. Built in China, this excavator features a robust backhoe bucket with a capacity of 0.9 to 1.1 m³, ensuring efficient digging and loading operations. Powered by a traditional engine delivering 118 kW at 2000 rpm, it offers reliable performance and durability. The SY205C boasts a ground specific pressure of 47.3 Kpa, allowing for stable operation on various terrains, and a climbing ability of 70% or 35°, making it versatile for different job sites.
- Bucket digging force: 138 kN
- Rod digging force: 109 kN
- Travel speed: 5.4/3.3 km/h
- Maximum digging depth: 6600 mm
- Maximum unloading height: 6730 mm
Available in 浙江绍兴, this unit is ready to integrate seamlessly into your existing fleet, providing the necessary backup and support to keep your projects on schedule and within budget.
| Specifications | Value |
|---|---|
| No. | 1023172 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.9~1.1(1.0) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 118/2000 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 109 |
| Travel speed (km/h) | 5.4/3.3 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4160 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3360 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
