Product Description
Built in 2020, this Sany SY205C-8 excavator delivers professional-grade performance at a fraction of new equipment costs. Manufactured in Kunshan, Jiangsu Province, this 20-ton machine combines proven reliability with exceptional value for contractors seeking maximum return on investment.
Powered by a Mitsubishi 6D34TL-20 engine producing 114kW at 2050rpm, this excavator handles demanding applications with ease. The 0.83m³ backhoe bucket generates 138kN of digging force, while dual hydraulic pumps flowing 420 l/min total ensure responsive operation across all functions.
- Maximum digging reach: 9,885mm with 6,630mm depth capability
- Working weight: 20,300kg for stable operation
- Travel speeds: 3.2/5.5 km/h for efficient site mobility
- Compact transport dimensions: 9,397mm × 2,800mm × 2,956mm
- Water-cooled engine with proven Mitsubishi technology
Currently located in Suqian, Jiangsu Province, this excavator represents smart capital allocation for businesses requiring reliable productivity without new equipment premiums. Specifications confirm factory-direct quality from one of China's leading manufacturers.
| Specifications | Value |
|---|---|
| No. | 1022663 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 20300 |
| Bucket capacity (m³) | 0.83 |
| Country of origin | Kunshan in Jiangsu Province |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Mitsubishi 6D34TL-20 |
| Rated power (kw/rpm) | 114/2050 |
| Cooling mode | water-cooling |
| Ground specific pressure (Kpa) | 44.8 |
| Rotation speed (rpm) | 12.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 138 |
| Travel speed (km/h) | 3.2/5.5 |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 2 x 210 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25.5 |
| Control Hydraulic Circuit (Mpa) | 3.9 |
| Hydraulic crushing pipeline is standard | no |
| Total transport length (mm) | 9397 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 2956 |
| Full cab height (mm) | 2930 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2750 |
| Total track length (mm) | 4064 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3260 |
| Maximum digging radius (mm) | 9885 |
| Maximum digging depth (mm) | 6630 |
| Maximum excavation height (mm) | 9305 |
| Maximum unloading height (mm) | 6475 |
| Maximum vertical digging depth (mm) | 5980 |
| Bulldozer lift or depth (mm) | There is no |
