Product Description
Built in 2021, this Sany SY205C-8 excavator represents proven Chinese engineering backed by one of the industry's most reliable support networks. Operating at 20 tons with a robust Mitsubishi 6D34TL-20 engine delivering 114kW, this machine combines substantial digging force (138kN) with the long-term parts availability that makes Sany a smart investment in the used equipment market.
Key specifications include:
- Maximum digging reach of 9,885mm and depth of 6,630mm
- 0.83m³ bucket capacity with powerful backhoe configuration
- Dual main pumps providing 2×210 L/min flow for responsive hydraulics
- Water-cooled system ensuring consistent performance in demanding conditions
- Compact transport dimensions (9,397mm length) for easier mobilization
Currently located in Suqian, Jiangsu Province, this SY205C-8 benefits from Sany's extensive dealer network across China and globally. With strong resale values and readily accessible OEM components, Sany machines minimize downtime and protect your investment—critical factors when purchasing used equipment for international operations.
| Specifications | Value |
|---|---|
| No. | 1022661 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 20300 |
| Bucket capacity (m³) | 0.83 |
| Country of origin | Kunshan in Jiangsu Province |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Mitsubishi 6D34TL-20 |
| Rated power (kw/rpm) | 114/2050 |
| Cooling mode | water-cooling |
| Ground specific pressure (Kpa) | 44.8 |
| Rotation speed (rpm) | 12.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 138 |
| Travel speed (km/h) | 3.2/5.5 |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 2 x 210 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25.5 |
| Control Hydraulic Circuit (Mpa) | 3.9 |
| Hydraulic crushing pipeline is standard | no |
| Total transport length (mm) | 9397 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 2956 |
| Full cab height (mm) | 2930 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2750 |
| Total track length (mm) | 4064 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3260 |
| Maximum digging radius (mm) | 9885 |
| Maximum digging depth (mm) | 6630 |
| Maximum excavation height (mm) | 9305 |
| Maximum unloading height (mm) | 6475 |
| Maximum vertical digging depth (mm) | 5980 |
| Bulldozer lift or depth (mm) | There is no |
