Product Description
Built in 2011, this Sany SY215C excavator delivers proven performance backed by one of China's most trusted heavy equipment manufacturers. Operating at 21 tons with a reliable Mitsubishi 4M50 engine producing 118kW, this machine combines robust digging force (138kN bucket, 103kN arm) with a versatile 1.1m³ bucket capacity suitable for diverse earthmoving applications. Maximum digging reach extends to 10,280mm with a depth capability of 6,600mm, while the water-cooled powertrain ensures consistent operation across demanding jobsites.
Sany's reputation for parts availability makes this SY215C a smart investment in the used equipment market. Global service networks and widespread component compatibility mean reduced downtime and lower long-term operating costs. With strong resale values driven by brand recognition across Asia, Africa, and emerging markets, this excavator offers both immediate productivity and future asset protection. Currently located in Jiangsu, China, the unit features standard undercarriage components (47 track plates per side, 600mm shoe width) and a 390L fuel capacity for extended work cycles.
| Specifications | Value |
|---|---|
| No. | 1040878 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21900 |
| Bucket capacity (m³) | 1.1 (0.8~1.2) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Mitsubishi 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 580/1600 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.4 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 390 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4250 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3445 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 47 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
