Product Description
Featuring a robust Mitsubishi 4M50 engine, this 2017 Sany SY215C excavator delivers 118 kW of power at 2000 rpm, ensuring reliable performance. With a working weight of 21,900 kg and a bucket capacity ranging from 0.8 to 1.2 m³, it is designed for efficiency and durability. Operators benefit from enhanced visibility in the full cab, which stands at 3075 mm, providing a clear view of the work area. The excavator's 47.4 Kpa ground specific pressure and 600 mm wide track plates ensure stability on various terrains. Its 138 kN bucket digging force and 103 kN rod digging force make it capable of handling tough excavation tasks. Traveling at speeds up to 5.4 km/h, the SY215C also offers a 390 L fuel tank, reducing downtime. Experience precise control and smooth operation with this well-engineered machine, ideal for construction and excavation projects.
| Specifications | Value |
|---|---|
| No. | 1020688 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21900 |
| Bucket capacity (m³) | 1.1 (0.8~1.2) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Mitsubishi 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 580/1600 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.4 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 390 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4250 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3445 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 47 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
