Product Description
Available now in 安徽, this 2017 Sany SY215C excavator delivers immediate deployment without factory wait times. Built for 21-ton class operations, this machine combines proven Mitsubishi 4M50 power with versatile performance across demanding jobsites. Skip the lead times and put this ready-to-work excavator into production within days of your order.
- Engine: Mitsubishi 4M50, 118 kW @ 2000 rpm, water-cooled, 4.9L displacement
- Performance: 10,280 mm max reach, 6,600 mm dig depth, 138 kN bucket force
- Capacity: 1.1 m³ bucket (adjustable 0.8–1.2 m³), 390L fuel tank for extended shifts
- Mobility: 5.4 km/h travel speed, 70% grading ability, 2,900 mm rear turning radius
- Specifications: 21,900 kg operating weight, 600 mm track shoes, 47 kPa ground pressure
Fast shipping from 安徽 ensures rapid deployment to your construction, mining, or infrastructure project. Backed by Sany's engineering standards and ready for immediate inspection, this SY215C eliminates downtime associated with new equipment orders. Contact us today for logistics coordination and site delivery scheduling.
| Specifications | Value |
|---|---|
| No. | 1027176 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21900 |
| Bucket capacity (m³) | 1.1 (0.8~1.2) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Mitsubishi 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 580/1600 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.4 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 390 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4250 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3445 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 47 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
