Product Description
Engineered with a powerful Mitsubishi 4M50 engine delivering 118 kW at 2000 rpm and 580 N·m maximum torque, this 2017 Sany SY215C combines proven Japanese powertrain technology with robust Chinese manufacturing. Operating at 21 tons with a 21,900 kg working weight, this excavator features impressive hydraulic performance: 138 kN bucket digging force and 103 kN rod digging force ensure consistent productivity across demanding jobsites. Its 1.1 m³ backhoe bucket (adjustable 0.8-1.2 m³) paired with a 10,280 mm maximum digging radius and 6,600 mm maximum depth provides exceptional versatility for medium to heavy-duty applications.
- Mitsubishi 4M50 water-cooled engine: 4.9L displacement, 4-cylinder configuration
- Superior reach: 10,280 mm digging radius, 9,600 mm excavation height
- Hydraulic capacity: 239L tank supporting high-performance cylinders
- Track stability: 600 mm plates, 3,445 mm ground contact length
- Operational range: 390L fuel tank for extended work cycles
- Climbing capability: 70% gradient (35°) with 47.4 kPa ground pressure
Currently located in Luzhou, Sichuan, this machine represents proven SY215C engineering reliability backed by comprehensive technical
| Specifications | Value |
|---|---|
| No. | 1033932 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21900 |
| Bucket capacity (m³) | 1.1 (0.8~1.2) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Mitsubishi 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 580/1600 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.4 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 390 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4250 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3445 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 47 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
