Product Description
Acquire proven excavation power without the premium price tag. This 2020 Sany SY215C delivers 21-ton performance with a Mitsubishi 4M50 engine rated at 118kW, offering exceptional value for contractors seeking reliable productivity. Operating weight of 21,900kg and bucket capacity up to 1.2m³ handle demanding earthmoving tasks with bucket digging force reaching 138kN. Water-cooled efficiency and 390L fuel capacity ensure extended operation cycles on job sites.
- Maximum digging reach: 10,280mm with 6,600mm depth capability
- Powerful hydraulics: 103kN arm force, 11rpm rotation speed
- Versatile mobility: 70% climbing ability, 5.4km/h travel speed
- Compact transport dimensions: 9,680mm × 2,980mm × 3,440mm
- Currently located in Guangxi, China—ready for global shipment
Backed by Sany's engineering reputation and minimal operating hours since 2020, this SY215C represents smart capital allocation. Pay significantly less than new equipment costs while securing a machine built for Chinese infrastructure projects. Investment-grade condition meets immediate deployment requirements for excavation, trenching, and material handling operations worldwide.
| Specifications | Value |
|---|---|
| No. | 1022228 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21900 |
| Bucket capacity (m³) | 1.1 (0.8~1.2) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Mitsubishi 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 580/1600 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.4 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 390 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4250 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3445 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 47 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
