2020 Sany SY215C

1/5
Buy Sany SY215C Used Excavator / 1
Buy Sany SY215C Used Excavator / 2
Buy Sany SY215C Used Excavator / 3
Buy Sany SY215C Used Excavator / 4
Buy Sany SY215C Used Excavator / 5

Product Description

Available now in Hunan—skip the factory lead times and put this proven 2020 Sany SY215C excavator to work immediately. Powered by a reliable Mitsubishi 4M50 engine delivering 118 kW at 2000 rpm, this 21-ton workhorse combines robust digging force (138 kN bucket, 103 kN arm) with a versatile 1.1 m³ bucket capacity. With a maximum digging reach of 10,280 mm and depth of 6,600 mm, it handles demanding earthmoving, trenching, and loading tasks across construction and mining sites.

  • Year: 2020
  • Model: Sany SY215C
  • Operating Weight: 21,900 kg
  • Engine: Mitsubishi 4M50, 118 kW, water-cooled
  • Bucket Capacity: 1.1 m³ (0.8–1.2 m³ range)
  • Max Digging Reach: 10,280 mm
  • Location: Hunan, China—ready for fast deployment

Reduce downtime with immediate availability. Comprehensive hydraulic systems, 390 L fuel capacity, and proven Chinese manufacturing ensure reliable performance. Contact us today for rapid logistics coordination and direct shipping to your site.

SpecificationsValue
No.1044450
Tonnage (tons)21
Working weight (kg)21900
Bucket capacity (m³)1.1 (0.8~1.2)
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeMitsubishi 4M50
Rated power (kw/rpm)118/2000
Cooling modewater-cooling
Maximum torque (N.m)580/1600
Number of cylinders (PCS)4
Displacement (L)4.9
Ground specific pressure (Kpa)47.4
Rotation speed (rpm)11
Climbing ability (%)70% (35°)
Bucket digging force (kN)138
Rod digging force (kN)103
Travel speed (km/h)5.4/3.3
Fuel Tank (L)390
Hydraulic Tank (L)239
Engine Oil changes (L)22
Total transport length (mm)9680
Total transport width (mm)2980
Total transport height (mm)3440
Full cab height (mm)3075
Minimum ground clearance (mm)440
Minimum turning radius of front working device (mm)3730
Back end turning radius (mm)2900
Onboard width (mm)2875
Total track length (mm)4250
Track gauge (mm)2380
Track plate width (mm)600
Track ground length (mm)3445
Maximum height at minimum turning radius (mm)7680
Number of sprockets (single side) (each)2
Number of wheels (single side) (each)8
Number of track plates (single side) (PCS)47
Maximum digging radius (mm)10280
Maximum digging depth (mm)6600
Maximum excavation height (mm)9600
Maximum unloading height (mm)6730
see more

Overview

No.1044450

Brand Name:

Sany

Model Number:

SY215C

Year:

2020

Location:

Hunan China

Pub Date
