Product Description
Built for demanding excavation, grading, and demolition work, this 2021 Sany SY215C delivers 21 tons of proven performance in a site-ready package. Powered by a Mitsubishi 4M50 engine generating 118kW at 2000rpm, this machine combines reliable traditional power with the precision hydraulics needed for deep foundation work, trenching, and material handling across construction and infrastructure projects.
With a maximum digging depth of 6,600mm and a reach extending to 10,280mm, this excavator tackles deep utility installations and wide-radius earthmoving with equal capability. The 1.1m³ backhoe bucket (adjustable 0.8-1.2m³) moves material efficiently, while 138kN bucket digging force and 103kN arm force cut through compacted soil and challenging ground conditions. Operating weight of 21,900kg provides stability during heavy lifting and slope work up to 70% grade.
- Mitsubishi 4M50 water-cooled diesel: 580N.m torque at 1600rpm
- Maximum excavation height: 9,600mm; unloading height: 6,730mm
- 390L fuel capacity for extended shifts without refueling
- Currently located in Maoming, Guangdong—ready for immediate deployment
| Specifications | Value |
|---|---|
| No. | 1028285 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21900 |
| Bucket capacity (m³) | 1.1 (0.8~1.2) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Mitsubishi 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 580/1600 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.4 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 390 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4250 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3445 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 47 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
