Product Description
Backed by one of China's top construction equipment manufacturers, this 2023 Sany SY215C delivers proven reliability in a 21-ton platform. Powered by a Mitsubishi 4M50 engine generating 118kW at 2000rpm, this excavator combines robust Japanese engine technology with Sany's established hydraulic systems. Operating weight of 21,900kg provides stability for demanding excavation tasks, while the 1.1m³ bucket capacity (adjustable 0.8-1.2m³) handles diverse material handling requirements.
Sany's extensive dealer network ensures parts availability across global markets, protecting your investment with accessible service support. Maximum digging depth reaches 6,600mm with 10,280mm working radius, supported by 138kN bucket digging force. The water-cooled engine and 390L fuel tank enable extended work cycles in challenging environments.
Key Specifications:
- Mitsubishi 4M50 engine: 118kW/2000rpm, 580N.m torque
- Working dimensions: 10,280mm reach, 6,600mm dig depth
- Transport size: 9,680mm × 2,980mm × 3,440mm
- Hydraulic capacity: 239L tank, 103kN arm force
- Currently located in Sichuan, China
| Specifications | Value |
|---|---|
| No. | 1022515 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21900 |
| Bucket capacity (m³) | 1.1 (0.8~1.2) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Mitsubishi 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 580/1600 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.4 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 390 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4250 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3445 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 47 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
