2013 Sany SY215C-8

1/6
Buy Sany SY215C-8 Used Excavator / 1
Buy Sany SY215C-8 Used Excavator / 2
Buy Sany SY215C-8 Used Excavator / 3
Buy Sany SY215C-8 Used Excavator / 4
Buy Sany SY215C-8 Used Excavator / 5
Buy Sany SY215C-8 Used Excavator / 6

Product Description

Built for the long haul, this 2013 Sany SY215C-8 excavator continues to prove why it remains a trusted workhorse on demanding job sites. Operating at 21 tons with a robust 20,900 kg working weight, this medium-class machine combines proven Mitsubishi 6D34-TL engine technology with Sany's durable construction standards. With over a decade of field-tested reliability, it delivers consistent performance across excavation, loading, and material handling applications.

  • Power & Performance: 114 kW rated power at 2050 rpm with water-cooled efficiency
  • Working Range: 9,885 mm maximum digging radius, 6,630 mm digging depth
  • Hydraulic Capacity: Dual 210 l/min pumps, 138 kN bucket digging force
  • Operational Specs: 0.93 m³ bucket capacity, 70% climbing ability
  • Mobility: 600 mm track plates, 440 mm ground clearance for varied terrain

Currently located in Ganzhou, Jiangxi, this machine represents proven engineering that has stood the test of time. Ready for immediate deployment on your next project.

SpecificationsValue
No.1047814
Tonnage (tons)21
Working weight (kg)20900
Bucket capacity (m³)0.93
Country of originKunshan in Jiangsu Province
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeMitsubishi 6D34-TL
Rated power (kw/rpm)114/2050
Cooling modewater-cooling
Ground specific pressure (Kpa)45
Rotation speed (rpm)12.5
Climbing ability (%)70/35 °
Bucket digging force (kN)138
Travel speed (km/h)3.2/5.5
Main overflow set pressure (Mpa)34.3
Maximum flow of main pump (l/min)2 x 210
Traveling Hydraulic Circuit (Mpa)34.3
Rotary Hydraulic Circuit (Mpa)25.5
Control Hydraulic Circuit (Mpa)3.9
Hydraulic crushing pipeline is standardno
Total transport length (mm)9397
Total transport width (mm)2980
Total transport height (mm)2956
Full cab height (mm)2930
Minimum ground clearance (mm)440
Back end turning radius (mm)2750
Total track length (mm)4250
Track gauge (mm)2380
Track plate width (mm)600
Total track width (mm)2980
Track ground length (mm)3445
Maximum digging radius (mm)9885
Maximum digging depth (mm)6630
Maximum excavation height (mm)9305
Maximum unloading height (mm)6475
Maximum vertical digging depth (mm)5980
Bulldozer lift or depth (mm)There is no
see more

Overview

No.1047814

Brand Name:

Sany

Model Number:

SY215C-8

Year:

2013

Location:

Jiangxi China

Pub Date
