HOME>>Sany>>Sany SY215C-8

2013 Sany SY215C-8

1/6
Buy Sany SY215C-8 Used Excavator / 1
Buy Sany SY215C-8 Used Excavator / 2
Buy Sany SY215C-8 Used Excavator / 3
Buy Sany SY215C-8 Used Excavator / 4
Buy Sany SY215C-8 Used Excavator / 5
Buy Sany SY215C-8 Used Excavator / 6

Product Description

This 2013 Sany SY215C-8 crawler excavator is available from Hunan, China. With approximately 8,800 operating hours, this 21-ton class machine has been maintained through regular service intervals and remains suitable for earthmoving, site development, and general construction applications.

Key specifications include:

  • Operating weight: approximately 21,500 kg
  • Engine: Isuzu diesel, meeting emission standards for its year
  • Bucket capacity: 0.9-1.0 m³ standard configuration
  • Hydraulic system designed for efficient cycle times
  • Cab with standard operator controls and visibility

The SY215C-8 represents Sany's mid-size excavator range from this production period. Current condition reflects normal wear consistent with documented hours. Inspection available upon request. Unit located in Hunan Province with logistics support for international shipping.

SpecificationsValue
No.1141297
Tonnage (tons)21
Working weight (kg)20900
Bucket capacity (m³)0.93
Country of originKunshan in Jiangsu Province
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeMitsubishi 6D34-TL
Rated power (kw/rpm)114/2050
Cooling modewater-cooling
Ground specific pressure (Kpa)45
Rotation speed (rpm)12.5
Climbing ability (%)70/35 °
Bucket digging force (kN)138
Travel speed (km/h)3.2/5.5
Main overflow set pressure (Mpa)34.3
Maximum flow of main pump (l/min)2 x 210
Traveling Hydraulic Circuit (Mpa)34.3
Rotary Hydraulic Circuit (Mpa)25.5
Control Hydraulic Circuit (Mpa)3.9
Hydraulic crushing pipeline is standardno
Total transport length (mm)9397
Total transport width (mm)2980
Total transport height (mm)2956
Full cab height (mm)2930
Minimum ground clearance (mm)440
Back end turning radius (mm)2750
Total track length (mm)4250
Track gauge (mm)2380
Track plate width (mm)600
Total track width (mm)2980
Track ground length (mm)3445
Maximum digging radius (mm)9885
Maximum digging depth (mm)6630
Maximum excavation height (mm)9305
Maximum unloading height (mm)6475
Maximum vertical digging depth (mm)5980
Bulldozer lift or depth (mm)There is no
see more

Overview

No.1141297

Brand Name:

Sany

Model Number:

SY215C-8

Year:

2013

Location:

Hunan China

Pub Date
