Product Description
Engineered for medium-duty excavation, this 2016 Sany SY215C-8 delivers exceptional value without compromising performance. Powered by a reliable Mitsubishi 6D34-TL engine producing 114kW at 2050 rpm, this 21-ton excavator handles demanding jobsites with proven efficiency. The 0.93m³ backhoe bucket generates 138kN of digging force, while the maximum digging depth of 6,630mm and reach of 9,885mm provide impressive working range for trenching, foundation work, and material handling.
Key Performance Specifications:
- Operating weight: 20,900kg with optimal stability
- Dual hydraulic pumps: 2 x 210 l/min for responsive control
- Travel speeds: 3.2/5.5 km/h for efficient repositioning
- 70% climbing ability tackles challenging terrain
- Water-cooled system ensures consistent operation
- Currently located in Beijing, ready for deployment
Investing in quality used equipment means acquiring professional-grade capabilities at a fraction of new equipment costs. This Sany excavator offers immediate ROI through reduced capital expenditure while maintaining the reliability and performance your projects demand. Smart contractors recognize that well-maintained pr
| Specifications | Value |
|---|---|
| No. | 1019508 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.93 |
| Country of origin | Kunshan in Jiangsu Province |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Mitsubishi 6D34-TL |
| Rated power (kw/rpm) | 114/2050 |
| Cooling mode | water-cooling |
| Ground specific pressure (Kpa) | 45 |
| Rotation speed (rpm) | 12.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 138 |
| Travel speed (km/h) | 3.2/5.5 |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 2 x 210 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25.5 |
| Control Hydraulic Circuit (Mpa) | 3.9 |
| Hydraulic crushing pipeline is standard | no |
| Total transport length (mm) | 9397 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 2956 |
| Full cab height (mm) | 2930 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2750 |
| Total track length (mm) | 4250 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2980 |
| Track ground length (mm) | 3445 |
| Maximum digging radius (mm) | 9885 |
| Maximum digging depth (mm) | 6630 |
| Maximum excavation height (mm) | 9305 |
| Maximum unloading height (mm) | 6475 |
| Maximum vertical digging depth (mm) | 5980 |
| Bulldozer lift or depth (mm) | There is no |
