Product Description
Equipped with a Mitsubishi 6D34-TL engine, this 2016 Sany SY215C-8 excavator delivers 114 kW of power at 2050 rpm, ensuring robust performance and efficiency. Featuring a water-cooling system, the machine maintains optimal operating temperatures even under demanding conditions. The hydraulic system is engineered for precision and strength, with a main overflow set pressure of 34.3 Mpa and a maximum flow of 2 x 210 l/min from the main pump.
- Working weight: 20,900 kg
- Bucket capacity: 0.93 m³
- Ground specific pressure: 45 Kpa
- Climbing ability: 70% / 35°
- Travel speed: 3.2/5.5 km/h
Manufactured in Kunshan, Jiangsu Province, China, this excavator boasts a backhoe bucket with a digging force of 138 kN, making it ideal for tough excavation tasks. Its total transport dimensions (9397 mm length, 2980 mm width, 2956 mm height) and compact turning radius (2750 mm) enhance maneuverability on various job sites. Engineered for durability and reliability, the SY215C-8 is a formidable choice for construction and excavation projects.
| Specifications | Value |
|---|---|
| No. | 1020321 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.93 |
| Country of origin | Kunshan in Jiangsu Province |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Mitsubishi 6D34-TL |
| Rated power (kw/rpm) | 114/2050 |
| Cooling mode | water-cooling |
| Ground specific pressure (Kpa) | 45 |
| Rotation speed (rpm) | 12.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 138 |
| Travel speed (km/h) | 3.2/5.5 |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 2 x 210 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25.5 |
| Control Hydraulic Circuit (Mpa) | 3.9 |
| Hydraulic crushing pipeline is standard | no |
| Total transport length (mm) | 9397 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 2956 |
| Full cab height (mm) | 2930 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2750 |
| Total track length (mm) | 4250 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2980 |
| Track ground length (mm) | 3445 |
| Maximum digging radius (mm) | 9885 |
| Maximum digging depth (mm) | 6630 |
| Maximum excavation height (mm) | 9305 |
| Maximum unloading height (mm) | 6475 |
| Maximum vertical digging depth (mm) | 5980 |
| Bulldozer lift or depth (mm) | There is no |
