Product Description
Strengthen your excavator fleet with this proven 2017 Sany SY215C-8, a 21-ton workhorse built for contractors who need reliable backup capacity. Manufactured in China with a robust Mitsubishi 6D34-TL engine delivering 114kW at 2050 rpm, this machine offers consistent power and water-cooled reliability across demanding jobsites. Currently located in Lishui, Zhejiang, it provides immediate availability for operators seeking to minimize equipment downtime.
Operational specifications include:
- 0.93 m³ bucket capacity with 138 kN digging force for productive excavation cycles
- 9.88-meter maximum reach and 6.63-meter digging depth for versatile applications
- Dual 210 l/min hydraulic pumps ensuring responsive control and smooth operation
- Compact 2.75-meter rear swing radius for confined work areas
- 70% gradeability and 5.5 km/h travel speed for efficient site mobility
With 20,900 kg working weight and 600mm track plates, this SY215C-8 balances stability with transportability. Add proven mid-size excavation capacity to your rental fleet or construction operations without the premium of new equipment pricing.
| Specifications | Value |
|---|---|
| No. | 1028757 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.93 |
| Country of origin | Kunshan in Jiangsu Province |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Mitsubishi 6D34-TL |
| Rated power (kw/rpm) | 114/2050 |
| Cooling mode | water-cooling |
| Ground specific pressure (Kpa) | 45 |
| Rotation speed (rpm) | 12.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 138 |
| Travel speed (km/h) | 3.2/5.5 |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 2 x 210 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25.5 |
| Control Hydraulic Circuit (Mpa) | 3.9 |
| Hydraulic crushing pipeline is standard | no |
| Total transport length (mm) | 9397 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 2956 |
| Full cab height (mm) | 2930 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2750 |
| Total track length (mm) | 4250 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2980 |
| Track ground length (mm) | 3445 |
| Maximum digging radius (mm) | 9885 |
| Maximum digging depth (mm) | 6630 |
| Maximum excavation height (mm) | 9305 |
| Maximum unloading height (mm) | 6475 |
| Maximum vertical digging depth (mm) | 5980 |
| Bulldozer lift or depth (mm) | There is no |
