Product Description
This 2017 Sany SY215C-8 crawler excavator represents a reliable mid-size earthmoving solution from one of China's leading heavy equipment manufacturers. Currently located in Jiangsu, China, this machine comes equipped with full Kawasaki hydraulic components, delivering dependable performance for demanding excavation, grading, and material handling applications.
The SY215C-8 is engineered for efficient operation in construction, infrastructure development, and general earthworks. With its Kawasaki hydraulic system configuration, operators can expect responsive controls and consistent productivity across varied jobsite conditions.
- Year of Manufacture: 2017
- Model: Sany SY215C-8
- Hydraulic System: Full Kawasaki configuration
- Current Location: Jiangsu Province, China
- Documentation: Detailed photos and video available upon request
Suitable for contractors seeking proven excavation capacity with established component reliability. Contact us for comprehensive visual documentation and specifications.
| Specifications | Value |
|---|---|
| No. | 1088311 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.93 |
| Country of origin | Kunshan in Jiangsu Province |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Mitsubishi 6D34-TL |
| Rated power (kw/rpm) | 114/2050 |
| Cooling mode | water-cooling |
| Ground specific pressure (Kpa) | 45 |
| Rotation speed (rpm) | 12.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 138 |
| Travel speed (km/h) | 3.2/5.5 |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 2 x 210 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25.5 |
| Control Hydraulic Circuit (Mpa) | 3.9 |
| Hydraulic crushing pipeline is standard | no |
| Total transport length (mm) | 9397 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 2956 |
| Full cab height (mm) | 2930 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2750 |
| Total track length (mm) | 4250 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2980 |
| Track ground length (mm) | 3445 |
| Maximum digging radius (mm) | 9885 |
| Maximum digging depth (mm) | 6630 |
| Maximum excavation height (mm) | 9305 |
| Maximum unloading height (mm) | 6475 |
| Maximum vertical digging depth (mm) | 5980 |
| Bulldozer lift or depth (mm) | There is no |
