Product Description
Engineered for demanding excavation operations, this 2014 SY215C-9 represents Sany's commitment to hydraulic excellence and robust construction. Powered by a 114kW engine operating at 2050 rpm, this 21-ton excavator delivers exceptional performance through its dual-pump hydraulic system, generating 2×210 l/min flow at 34.3 MPa main circuit pressure. The water-cooled powertrain ensures consistent operation under sustained workloads.
Technical capabilities include:
- Bucket digging force: 138 kN with 0.93 m³ capacity (0.8-1.2 m³ range)
- Maximum digging reach: 9,950 mm with 6,600 mm depth capability
- Operating weight: 21,800 kg with optimized 46.5 kPa ground pressure
- Climbing ability: 70% gradient (35° angle)
- Dual-speed travel: 5.4/3.3 km/h for operational flexibility
Currently located in Jinan, Shandong, this Shanghai-manufactured unit demonstrates the SY215C-9 series' engineering integrity. The precision hydraulic controls, reinforced undercarriage with 3,445 mm track ground contact, and 9,570 mm maximum excavation height make this machine suitable for infrastructure, mining, and heavy construction applications.
| Specifications | Value |
|---|---|
| No. | 1006504 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21800 |
| Bucket capacity (m³) | 0.93 (0.8~1.2) |
| Country of origin | Shanghai |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 114/2050 |
| Cooling mode | water-cooling |
| Ground specific pressure (Kpa) | 46.5 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 2 x 210 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25.5 |
| Control Hydraulic Circuit (Mpa) | 3.9 |
| Hydraulic crushing pipeline is standard | no |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 2990 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3595 |
| Back end turning radius (mm) | 2890 |
| Onboard width (mm) | 2710 |
| Total track length (mm) | 4250 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 (800/700 optional) |
| Total track width (mm) | 2980 |
| Track ground length (mm) | 3445 |
| Maximum digging radius (mm) | 9950 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9570 |
| Maximum unloading height (mm) | 6700 |
| Maximum vertical digging depth (mm) | 5800 |
| Bulldozer lift or depth (mm) | There is no |
| Dodging plate width × height (mm) | There is no |
| Maximum excavation radius of stop surface (mm) | 9885 |
