Product Description
Engineered for demanding excavation operations, this 2014 SY215C-9 represents Sany's commitment to hydraulic excellence and robust construction. Powered by a 114kW engine operating at 2050 rpm, this 21-ton excavator delivers exceptional performance through its dual-pump hydraulic system, generating 2×210 l/min flow at 34.3 MPa main circuit pressure. The water-cooled powertrain ensures consistent operation under sustained workloads.
Technical specifications demonstrate superior capability: 138kN bucket digging force and 103kN arm digging force enable efficient material handling across diverse applications. The 0.93m³ bucket capacity (adjustable 0.8-1.2m³) combines with a 9950mm maximum digging radius and 6600mm digging depth to provide extensive working range. Operational versatility is enhanced by 70% gradeability and 5.4 km/h travel speed.
Key performance features include:
- Rated power: 114kW at 2050 rpm with water-cooling system
- Hydraulic flow: Dual 210 l/min pumps for responsive control
- Working weight: 21,800kg with 46.5 kPa ground pressure
- Maximum reach: 9950mm radius, 9570mm digging height
- Transport dimensions: 9680×2980×3440mm
Currently located in Y
| Specifications | Value |
|---|---|
| No. | 997311 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21800 |
| Bucket capacity (m³) | 0.93 (0.8~1.2) |
| Country of origin | Shanghai |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 114/2050 |
| Cooling mode | water-cooling |
| Ground specific pressure (Kpa) | 46.5 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 2 x 210 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25.5 |
| Control Hydraulic Circuit (Mpa) | 3.9 |
| Hydraulic crushing pipeline is standard | no |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 2990 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3595 |
| Back end turning radius (mm) | 2890 |
| Onboard width (mm) | 2710 |
| Total track length (mm) | 4250 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 (800/700 optional) |
| Total track width (mm) | 2980 |
| Track ground length (mm) | 3445 |
| Maximum digging radius (mm) | 9950 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9570 |
| Maximum unloading height (mm) | 6700 |
| Maximum vertical digging depth (mm) | 5800 |
| Bulldozer lift or depth (mm) | There is no |
| Dodging plate width × height (mm) | There is no |
| Maximum excavation radius of stop surface (mm) | 9885 |
