Product Description
Built for demanding excavation work, this 2014 Sany SY215W wheeled excavator delivers 21.5 tons of working capability with exceptional operator-focused engineering. Powered by an Isuzu 4HK1 engine generating 128.4 kW at 2000 rpm, this machine combines reliable fuel efficiency with strong hydraulic performance across varied terrain in Yunnan province.
Operators benefit from enhanced maneuverability with 38 km/h forward speed and 11.9 rpm rotation capability, enabling rapid repositioning between work zones. Cabin design from this era prioritizes all-around visibility for precise bucket placement, while the wheeled chassis provides stable operation on both paved and compact surfaces. Hydraulic systems deliver 117.5 kN bucket digging force and 102.9 kN arm force through a 0.93 m³ capacity bucket.
- Working Weight: 21,500 kg
- Engine: Isuzu 4HK1, 5.193L displacement
- Maximum Torque: 670 N·m at 1600 rpm
- Climbing Ability: 35°
- Fuel Capacity: 400L for extended shifts
- Hydraulic Tank: 230L
- Current Location: Yunnan, China
| Specifications | Value |
|---|---|
| No. | 1016679 |
| Tonnage (tons) | 21.5 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.93 |
| power | Fuel oil |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Isuzu 4HK1 |
| Rated power (kw/rpm) | 128.4/2000 |
| Total displacement (L) | 5.193 |
| Maximum torque (N.m) | 670/1600 |
| Forward speed (Km/h) | 38/10 |
| Rotation speed (rpm) | 11.9 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 117.5 |
| Rod digging force (kN) | 102.9 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 230 |
| Engine Oil changes (L) | 20 |
