Product Description
Expand your operational capacity with this 2014 Sany SY225C excavator, a proven 23-ton workhorse engineered for reliable fleet integration. Powered by a robust 4M50 engine delivering 118 kW at 2000 rpm, this Chinese-manufactured crawler excels as a backup unit or primary addition to demanding contractor fleets. Maximum digging reach extends to 10,280 mm with a depth capability of 6,600 mm, while the 1.1-1.2 m³ backhoe bucket generates 138 kN of digging force—sufficient for site preparation, trenching, and loading operations.
- Fleet-Ready Performance: 22,300 kg operating weight balances productivity with transportability across jobsites
- Extended Uptime: 340L fuel tank and accessible 239L hydraulic reservoir minimize refueling interruptions
- Versatile Mobility: 70% gradeability and 5.4 km/h travel speed maintain productivity on varied terrain
- Compact Transport: 9,680 mm length fits standard lowboy trailers for efficient relocation
Currently located in Luzhou, Sichuan, this machine offers immediate availability for contractors requiring dependable supplemental capacity. Ideal for construction firms managing multiple
| Specifications | Value |
|---|---|
| No. | 1025685 |
| Tonnage (tons) | 23 |
| Working weight (kg) | 22300 |
| Bucket capacity (m³) | 1.1~1.2(1.2) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Maximum torque (N.m) | 580/1600 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.4 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 2 |
| Coolant (L) | 30.9 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Counterweight ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3640 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 47 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
