Product Description
Secure a proven performer without the factory wait. This 2020 Sany SY225C excavator is available now in Sichuan Luzhou, ready for immediate deployment to your project site. Powered by a robust 4M50 engine delivering 118kW at 2000rpm, this 23-ton workhorse combines 138kN bucket digging force with a 10,280mm maximum digging radius for superior productivity across mining, infrastructure, and earthmoving applications.
- Operating Weight: 22,300 kg with 1.1-1.2m³ bucket capacity
- Engine: 4.9L displacement, 580N·m maximum torque
- Performance: 6,600mm max digging depth, 9,600mm max excavation height
- Mobility: 5.4 km/h travel speed, 70% grading capability
- Transport Dimensions: 9,680 × 2,980 × 3,440mm
Skip months of factory lead times and logistics uncertainty. Made in China with established service networks nationwide, this SY225C is positioned in Sichuan Luzhou for fast deployment across Western China and beyond. Inspect today, operate tomorrow—no production delays, no backorders, just immediate capability when your schedule demands it.
| Specifications | Value |
|---|---|
| No. | 1023598 |
| Tonnage (tons) | 23 |
| Working weight (kg) | 22300 |
| Bucket capacity (m³) | 1.1~1.2(1.2) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Maximum torque (N.m) | 580/1600 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.4 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 2 |
| Coolant (L) | 30.9 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Counterweight ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3640 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 47 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
