Product Description
This 2021 Sany SY225C hydraulic excavator represents exceptional value in the mid-size excavator segment. With minimal operating hours in the low 2000s, this machine has seen limited use and remains in excellent working condition. Currently located in Fujian, China, this unit offers reliable performance for construction, earthmoving, and general excavation applications.
The SY225C is engineered with Sany's proven hydraulic system and durable undercarriage components, delivering consistent productivity in demanding work environments. This model balances power and fuel efficiency, making it suitable for contractors seeking dependable equipment without the premium of new machinery.
- Year of Manufacture: 2021
- Operating Hours: Low 2000s
- Current Location: Fujian Province, China
- Condition: Well-maintained, ready for operation
- Application: Construction, excavation, earthmoving
Available for immediate inspection and export arrangements. Contact us for detailed specifications and shipping solutions.
| Specifications | Value |
|---|---|
| No. | 1086465 |
| Tonnage (tons) | 23 |
| Working weight (kg) | 22300 |
| Bucket capacity (m³) | 1.1~1.2(1.2) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Maximum torque (N.m) | 580/1600 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.4 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 2 |
| Coolant (L) | 30.9 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Counterweight ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3640 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 47 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
