Product Description
Ready to deploy from Guizhou, this 2019 Sany SY225H excavator eliminates factory lead times and puts 22 tons of proven Chinese engineering on your site fast. Built for demanding operations, it delivers 133 kW rated power and 140 kN bucket digging force through a robust 5.2L diesel engine. Available now for immediate shipment, this machine represents practical value without the wait—ideal for contractors who need reliable performance on tight project schedules.
- Operating Weight: 22,800 kg with 1.2 m³ bucket capacity
- Power & Performance: 133 kW at 2,000 rpm; maximum torque 657 N·m
- Hydraulic Capability: 140 kN bucket force, 107 kN arm force
- Mobility: 5.6 km/h travel speed, 70% grading ability, 10.8 rpm swing speed
- Fuel Capacity: 370L tank for extended operation
- Track Configuration: 600 mm shoes, 8 rollers per side for stable ground contact
- Location: Guizhou—available for fast deployment across China and international markets
Skip prolonged procurement cycles. This unit is inspected, documented, and ready for logistics coord
| Specifications | Value |
|---|---|
| No. | 1016595 |
| Tonnage (tons) | 22 |
| Working weight (kg) | 22800 |
| Bucket capacity (m³) | 1.1-1.2(1.2) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 133/2000 |
| Maximum torque (N.m) | 657/1500 |
| Displacement (L) | 5.193 |
| Ground specific pressure (Kpa) | 51 |
| Rotation speed (rpm) | 10.8 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 140 |
| Rod digging force (kN) | 107 |
| Travel speed (km/h) | 5.6/3.3 |
| Turning torque (kN/m) | 657/1500 |
| Fuel Tank (L) | 370 |
| Hydraulic Tank (L) | 270 |
| Engine Oil changes (L) | 21.5 |
| Coolant (L) | 33 |
| Track plate width (mm) | 600 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 47 |
