Product Description
This 2013 Sany SY235C-8 hydraulic excavator represents reliable mid-size earthmoving capability from one of China's leading heavy equipment manufacturers. Located in Sichuan, China, this machine offers the durability and performance characteristics typical of Sany's 23-ton class excavators.
The SY235C-8 features a robust design suitable for construction, excavation, and material handling applications. With over a decade of proven operation, this unit demonstrates the longevity of Sany's engineering standards.
- Operating weight: Approximately 23,500 kg
- Bucket capacity: Standard 1.0-1.2 m³ range
- Diesel-powered hydraulic system
- Suitable for general earthmoving and construction projects
- Currently located in Sichuan Province, China
This excavator is available for inspection and immediate deployment. Contact us for detailed specifications, current condition assessment, and export arrangements to your location.
| Specifications | Value |
|---|---|
| No. | 1080847 |
| Tonnage (tons) | 23 |
| Working weight (kg) | 22900 |
| Bucket capacity (m³) | 1 |
| Country of origin | Kunshan in Jiangsu Province |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 125/2100 |
| Cooling mode | water-cooling |
| Ground specific pressure (Kpa) | 47.6 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 159 |
| Travel speed (km/h) | 3.2/5.5 |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 2 x 265 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25.5 |
| Control Hydraulic Circuit (Mpa) | 3.9 |
| Hydraulic crushing pipeline is standard | no |
| Total transport length (mm) | 9780 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3160 |
| Full cab height (mm) | 2930 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2860 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2980 |
| Track ground length (mm) | 3640 |
| Maximum digging radius (mm) | 10180 |
| Maximum digging depth (mm) | 6920 |
| Maximum excavation height (mm) | 9380 |
| Maximum unloading height (mm) | 6515 |
| Maximum vertical digging depth (mm) | 6010 |
| Bulldozer lift or depth (mm) | There is no |
