Product Description
With a working weight of 22,900 kg and a powerful 125 kW engine, this 2016 Sany SY235C-8 excavator is designed for robust performance. Located in 浙江宁波, it's available now, ready to be deployed to your site without the usual factory lead times. Featuring a 1 m³ bucket capacity and a maximum digging depth of 6,920 mm, it ensures efficient and effective operation. The machine offers a travel speed of up to 5.5 km/h, making it ideal for quick relocation on job sites. Equipped with water-cooling and a ground specific pressure of 47.6 Kpa, it maintains stability and efficiency even in challenging terrains. Fast deployment from our 浙江宁波 location means you can start your project sooner, maximizing productivity and minimizing downtime.
- Rated power: 125 kW/2100 rpm
- Bucket capacity: 1 m³
- Travel speed: 3.2/5.5 km/h
- Maximum digging depth: 6,920 mm
- Available now, skip the factory lead times
| Specifications | Value |
|---|---|
| No. | 1033584 |
| Tonnage (tons) | 23 |
| Working weight (kg) | 22900 |
| Bucket capacity (m³) | 1 |
| Country of origin | Kunshan in Jiangsu Province |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Rated power (kw/rpm) | 125/2100 |
| Cooling mode | water-cooling |
| Ground specific pressure (Kpa) | 47.6 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 159 |
| Travel speed (km/h) | 3.2/5.5 |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 2 x 265 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25.5 |
| Control Hydraulic Circuit (Mpa) | 3.9 |
| Hydraulic crushing pipeline is standard | no |
| Total transport length (mm) | 9780 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3160 |
| Full cab height (mm) | 2930 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2860 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2980 |
| Track ground length (mm) | 3640 |
| Maximum digging radius (mm) | 10180 |
| Maximum digging depth (mm) | 6920 |
| Maximum excavation height (mm) | 9380 |
| Maximum unloading height (mm) | 6515 |
| Maximum vertical digging depth (mm) | 6010 |
| Bulldozer lift or depth (mm) | There is no |
