Product Description
Built to endure the toughest jobsites, this 2016 Sany SY235C-9 excavator demonstrates proven reliability through years of consistent performance. Operating at 23 tons with a robust 24,200 kg working weight, this machine combines Shanghai engineering excellence with the dependable ISUZU 6BG1 six-cylinder turbocharged engine, delivering 128.5 kW of rated power at 2100 rpm. Currently located in Luzhou, Sichuan, this workhorse features impressive digging capabilities with 175 kN bucket force and 122 kN rod force, backed by a 1.1 m³ bucket capacity for substantial material handling.
- Maximum digging reach: 10,150 mm with 6,785 mm depth capability
- Superior climbing ability: 70% grade (35°) for challenging terrain
- Efficient rotation speed: 11 rpm for productive cycle times
- Stable ground pressure: 47.6 kPa minimizes surface damage
- Versatile track options: 600 mm standard (700/800 mm available)
- Proven ISUZU power: Four-stroke direct injection reliability
With nearly a decade of operational history, this SY235C-9 represents time-tested Chinese manufacturing quality. Its comprehensive transport dimensions (9,920 × 2,980 × 3,550 mm) and dual travel speeds ensur
| Specifications | Value |
|---|---|
| No. | 1010696 |
| Tonnage (tons) | 23 |
| Working weight (kg) | 24200 |
| Bucket capacity (m³) | 1.1 (Optional 1.1 to 1.2) |
| Country of origin | Shanghai |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | ISUZU 6BG1 |
| Rated power (kw/rpm) | 128.5/2100 |
| Number of cylinders (PCS) | 6-cylinder |
| Working form | Four-stroke, six-cylinder turbocharged direct injection engine |
| Ground specific pressure (Kpa) | 47.6 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 175 |
| Rod digging force (kN) | 122 |
| Travel speed (km/h) | 5.5/3.5 |
| Total transport length (mm) | 9920 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3550 |
| Full cab height (mm) | 2990 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3800 |
| Back end turning radius (mm) | 2890 |
| Onboard width (mm) | 2710 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 (800/700 optional) |
| Total track width (mm) | 2980 |
| Track ground length (mm) | 3640 |
| Maximum height at minimum turning radius (mm) | 7940 |
| Maximum digging radius (mm) | 10150 |
| Maximum digging depth (mm) | 6785 |
| Maximum excavation height (mm) | 9640 |
| Maximum unloading height (mm) | 6725 |
| Maximum vertical digging depth (mm) | 5845 |
