Product Description
Powered by a fuel-efficient National IV emission-compliant engine, the 2023 Sany SY235H delivers 129 kW of reliable power paired with advanced hydraulic architecture designed for optimal flow control and reduced cycle times. This 23.5-ton excavator incorporates Sany's latest engineering refinements, including reinforced boom structures, precision load-sensing hydraulics, and enhanced fuel management systems that reduce operating costs without compromising performance.
Currently located in Sichuan, this machine represents the H-series evolution—a platform engineered for demanding jobsites requiring both power and efficiency. Key technical advantages include:
- Advanced hydraulic system with multi-mode operation for task-specific power delivery
- Strengthened undercarriage components rated for extended service intervals
- Intelligent monitoring system providing real-time diagnostics and performance data
- Optimized swing torque and digging force for superior material handling capacity
Built to Chinese National IV standards, this SY235H combines regulatory compliance with proven mechanical durability, making it suitable for infrastructure projects, earthmoving operations, and heav
| Specifications | Value |
|---|---|
| No. | 1014155 |
| Tonnage (tons) | 23 |
| Working weight (kg) | 23000 |
| Bucket capacity (m³) | 1.35 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Deutz TCD5.7/ Isuzu 4HK1 |
| Rated power (kw/rpm) | 129/2100; 128/2000 |
| Emission standard | Country IV |
| Ground specific pressure (Kpa) | 51 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 140 |
| Rod digging force (kN) | 107 |
| Travel speed (km/h) | 5.6/3.5 |
| Total transport length (mm) | 9635 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3100 |
| Full cab height (mm) | 3255 |
| Minimum ground clearance (mm) | 442 |
| Minimum turning radius of front working device (mm) | 3662 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2813 |
| Total track length (mm) | 4446 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3640 |
| Maximum height at minimum turning radius (mm) | 7600 |
| Maximum digging radius (mm) | 9735 |
| Maximum digging depth (mm) | 6450 |
| Maximum excavation height (mm) | 9470 |
| Maximum unloading height (mm) | 6735 |
