2016 Sany SY245H

1/4
Used Sany SY245H Excavator 2016 Model / 1
Used Sany SY245H Excavator 2016 Model / 2
Used Sany SY245H Excavator 2016 Model / 3
Used Sany SY245H Excavator 2016 Model / 4

Product Description

Engineered for demanding excavation work, this 2016 Sany SY245H delivers operator-centric performance where it matters most. Equipped with China IV emission standards, this 24-ton class excavator combines robust hydraulic power with refined control systems designed to reduce operator fatigue during extended shifts.

Cabin design prioritizes visibility and comfort. Operators benefit from:

  • Expansive glass panels providing superior sightlines to bucket, tracks, and surrounding work zones
  • Ergonomic control layout minimizing repetitive strain during precision operations
  • Reinforced undercarriage delivering stable performance on uneven terrain
  • Responsive hydraulic systems enabling smooth, predictable machine handling
  • Climate-controlled environment maintaining productivity in Guangxi's variable conditions

Currently located in Guangxi, this SY245H represents proven mid-size excavator capability. Hydraulic stability and low-effort joystick control allow operators to maintain accuracy throughout the workday. For contractors requiring dependable performance with operator welfare in mind, this machine offers practical value backed by Sany's established engineering standards.

SpecificationsValue
No.1005853
Tonnage (tons)25
Working weight (kg)25500
Bucket capacity (m³)1.4
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeDeutz
Rated power (kw/rpm)150/2100
Ground specific pressure (Kpa)52.5
Rotation speed (rpm)10
Climbing ability (%)70
Bucket digging force (kN)175(187)
Rod digging force (kN)120(129)
Travel speed (km/h)5.8/3.7
Total transport length (mm)10290
Total transport width (mm)3190
Total transport height (mm)3255
Full cab height (mm)3255
Minimum ground clearance (mm)470
Minimum turning radius of front working device (mm)3800
Back end turning radius (mm)3105
Onboard width (mm)3045
Total track length (mm)4445
Track gauge (mm)2590
Track plate width (mm)600
Track ground length (mm)3640
Maximum height at minimum turning radius (mm)8016
Maximum digging radius (mm)10225
Maximum digging depth (mm)6705
Maximum excavation height (mm)9745
Maximum unloading height (mm)6715
Maximum vertical digging depth (mm)5675
see more

Overview

No.1005853

Brand Name:

Sany

Model Number:

SY245H

Year:

2016

Location:

Guangxi China
