Product Description
Built in 2016, this Sany SY245H hydraulic excavator delivers proven 24-ton performance with the operational security that comes from choosing a globally recognized Chinese manufacturer. Powered by a robust D06FRC engine producing 147 kW at 2100 rpm, this machine combines 175 kN bucket digging force with a 10,225 mm maximum reach, making it capable of handling demanding excavation, loading, and earthmoving applications. Currently located in Dezhou, Shandong, this unit represents exceptional value in the used equipment market.
Why Sany Matters in the Used Market:
- Parts Accessibility: Extensive global dealer network ensures replacement components arrive quickly and affordably
- Service Support: Factory-backed technical documentation and widespread mechanic familiarity reduce downtime
- Resale Confidence: Strong brand recognition in Asia, Africa, and emerging markets protects your investment
- Proven Durability: Water-cooled 6-cylinder engine and reinforced undercarriage deliver reliable performance beyond initial ownership
With a 1.3-1.5 m³ bucket capacity, 475 L fuel tank, and 70% climbing abili
| Specifications | Value |
|---|---|
| No. | 1026100 |
| Tonnage (tons) | 24 |
| Working weight (kg) | 25500 |
| Bucket capacity (m³) | 1.3~1.5(1.5) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | D06FRC |
| Rated power (kw/rpm) | 147/2100 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 750/1350 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.373 |
| Ground specific pressure (Kpa) | 53.2 |
| Rotation speed (rpm) | 10.6 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 175 |
| Rod digging force (kN) | 120 |
| Travel speed (km/h) | 5.4/3.4 |
| Fuel Tank (L) | 475 |
| Hydraulic Tank (L) | 277 |
| Engine Oil changes (L) | 29 |
| Total transport length (mm) | 10290 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3190 |
| Full cab height (mm) | 3255 |
| Minimum ground clearance (mm) | 470 |
| Minimum turning radius of front working device (mm) | 3800 |
| Back end turning radius (mm) | 3105 |
| Onboard width (mm) | 3045 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3640 |
| Maximum height at minimum turning radius (mm) | 8016 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 10225 |
| Maximum digging depth (mm) | 6705 |
| Maximum excavation height (mm) | 9745 |
| Maximum unloading height (mm) | 6715 |
