2017 Sany SY245H

1/7
Buy Sany SY245H Used Excavator / 1
Buy Sany SY245H Used Excavator / 2
Buy Sany SY245H Used Excavator / 3
Buy Sany SY245H Used Excavator / 4
Buy Sany SY245H Used Excavator / 5
Buy Sany SY245H Used Excavator / 6
Buy Sany SY245H Used Excavator / 7

Product Description

This 2017 Sany SY245H hydraulic excavator represents a solid mid-size solution for contractors seeking reliable performance in earthmoving and construction applications. As a single-owner machine with documented service history, this unit has been maintained in Fujian, China, and shows consistent operational readiness.

The SY245H is built on Sany's proven platform, delivering dependable hydraulic performance and fuel efficiency in the 24-ton class. This model is well-suited for general excavation, trenching, material handling, and site preparation work.

  • Year: 2017
  • Model: Sany SY245H
  • Operating weight: Approximately 24,500 kg
  • Single previous owner
  • Current location: Fujian Province, China
  • Available for inspection by appointment

Ideal for buyers seeking a mid-range excavator with established service records and straightforward operational history. Contact us for detailed specifications and viewing arrangements.

SpecificationsValue
No.1074768
Tonnage (tons)24
Working weight (kg)25500
Bucket capacity (m³)1.3~1.5(1.5)
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeD06FRC
Rated power (kw/rpm)147/2100
Cooling modewater-cooling
Maximum torque (N.m)750/1350
Number of cylinders (PCS)6
Displacement (L)6.373
Ground specific pressure (Kpa)53.2
Rotation speed (rpm)10.6
Climbing ability (%)70
Bucket digging force (kN)175
Rod digging force (kN)120
Travel speed (km/h)5.4/3.4
Fuel Tank (L)475
Hydraulic Tank (L)277
Engine Oil changes (L)29
Total transport length (mm)10290
Total transport width (mm)3190
Total transport height (mm)3190
Full cab height (mm)3255
Minimum ground clearance (mm)470
Minimum turning radius of front working device (mm)3800
Back end turning radius (mm)3105
Onboard width (mm)3045
Total track length (mm)4445
Track gauge (mm)2590
Track plate width (mm)600
Track ground length (mm)3640
Maximum height at minimum turning radius (mm)8016
Number of sprockets (single side) (each)2
Number of wheels (single side) (each)9
Number of track plates (single side) (PCS)49
Maximum digging radius (mm)10225
Maximum digging depth (mm)6705
Maximum excavation height (mm)9745
Maximum unloading height (mm)6715
